THÔNG SỐ KỸ THUẬT :
| Product characteristics | |||
|---|---|---|---|
| Electrical design | PNP | ||
| Output function | normally open | ||
| Sensing range [mm] | 12 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M18 x 1 / L = 65 | ||
| Application | |||
| Special feature | Gold-plated contacts; Increased sensing range; Correction factor K = 1; Magnetic-field immune; anti-spatter | ||
| Application | Use in welding applications | ||
| Magnetic-field immune | yes | ||
| Max. magnetic field immunity [mT] | 300 | ||
| Electrical data | |||
| Operating voltage [V] | 10…30 DC | ||
| Current consumption [mA] | < 20 | ||
| Protection class | II | ||
| Reverse polarity protection | yes | ||
| Outputs | |||
| Electrical design | PNP | ||
| Output function | normally open | ||
| Max. voltage drop switching output DC [V] | 2.5 | ||
| Permanent current rating of switching output DC [mA] | 100 | ||
| Switching frequency DC [Hz] | 2000 | ||
| Short-circuit protection | yes | ||
| Overload protection | yes | ||
| Detection zone | |||
| Sensing range [mm] | 12 | ||
| Real sensing range Sr [mm] | 12 ± 10 % | ||
| Operating distance [mm] | 0…9.72 | ||
| Increased sensing range | yes | ||
| Accuracy / deviations | |||
| Correction factor | steel: 1 / stainless steel: 1 / brass: 1 / aluminium: 1 / copper: 1 | ||
| Hysteresis [% of Sr] | 3…15 | ||
| Switch point drift [% of Sr] | -10…10 | ||
| Correction factor K = 1 | yes | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…70 | ||
| Protection | IP 67 | ||
| Mechanical data | |||
| Weight [K40] | 46.2 | ||
| Housing | threaded type | ||
| Mounting | non-flush mountable | ||
| Dimensions [mm] | M18 x 1 / L = 65 | ||
| Thread designation | M18 x 1 | ||
| Materials | housing: brass anti-spatter; sensing face: LCP black; LED window: PEI; lock nuts: brass anti-spatter | ||
| Displays / operating elements | |||
| Display |
|
||
| Accessories | |||
| Accessories (supplied) |
|
||
| Remarks | |||
| Pack quantity | 1 pcs. | ||
| Electrical connection – plug | |||
| Connection | Connector: 1 x M12; Contacts: gold-plated | ||
Thông tin bổ sung
| Thương hiệu |
IFM |
|---|---|
| Thời gian bảo hành |
1 Năm |
| Khoảng cách phát hiện |
12mm |
| Tín hiệu ngõ ra |
NO, PNP |
